FrameScalpel, Series 1 Carbon construction, 120mm travel, Proportional Response Suspension and Geometry, FlexPivot Chainstay, full internal cable routing, 73mm BSA, 1.5″ headtube with 1-1/8″ upper reducer/internal cable guide, 148x12mm thru axle, 55mm chainline, UDH, post-mount disc – 160mm native
ForkLefty Ocho 120 Carbon, 120mm, Chamber Damper, OppO Spring System, tapered steerer, 50mm offset, TwistLoc Ultimate remote dual lockout
HeadsetAcros ICR
Rear ShockRockShox SIDLuxe Select+, 2-Pos mode adjust, adjustable rebound, 190×45, TwistLoc Ultimate remote dual lockout
Rear DerailleurSRAM XO Eagle AXS, T-Type
ShiftersSRAM AXS T-Type Pod Controller
ChainSRAM XO, T-Type, 12-speed
CrankSRAM XO, T-Type, 34T
Rear CogsSRAM XO Eagle, 10-52, T-Type, 12-speed
Bottom BracketSRAM DUB BSA 73mm MTB Wide
BrakesSRAM Level Silver Stealth, 4-piston hydraulic disc, SRAM HS2 180/160mm rotors
Brake LeversSRAM Level Silver Stealth
RimsDT Swiss XRC 1501 SPLINE ONE, carbon, 30mm inner width, hookless, TSS tubeless ready
SpokesDT Competition Race, straight pull
Tire Size2.4
Wheel Size29
HubsDT Swiss Lefty, 6-bolt (F) / 240 Ratchet EXP 36, 6-bolt, XD driver (R)
Tires(F) Maxxis Rekon Race WT, 29×2.4″, EXO Protection, tubeless ready / (R) Maxxis Aspen WT, 29×2.4″, EXO Protection, tubeless ready
HandlebarSystemBar XC-One Flat, carbon, integrated bar/stem, internal cable routing, 5° upsweep, 8° backsweep, 760mm width, -6° stem, 1-1/8″ clamp
StemSystemBar XC-One Flat, carbon integrated bar/stem
GripsRockShox Smooth Silicone
SaddlePrologo Dimension NDR, Tirox rails
SeatpostFox Transfer SL Performance Elite, 31.6, 125mm (S), 150mm (M-XL)
To reduce production and delivery times the supplier sometimes have to make last-minute changes to product specifications. These updates may not always be reflected in the product descriptions or images on our website.
